Description
Brought to you by Torus, our specialist testing brand, the Torus Z301 Trimmed Can Front End Gauge features fixed-top and mid-wall probe positions for multi-positional radial measurement, with a dedicated caliper to ensure the correct top and mid-wall thickness measurement positions every time. Also available in manual bench top and floor standing semi-automatic options.

Measurement Features

• Trimmed Can Height | 1-16 positions | Accuracy: +- 0.010 mm
• Top Wall Thickness | 1-16 positions | Accuracy: +- 0.010 mm
• Upper Mid Wall Thickness | 1-16 positions | Accuracy: +- 0.010 mm
• Lower Mid Wall Thickness | 1-16 positions | Accuracy: +- 0.010 mm
• Wall Step
• Dome Depth | Single Point | Accuracy: +/- 0.010 mm

Specifications
SKU: Torus_Z301_A_TRIMMEDCAN
Applications: Optical Testing
Materials: Aluminum, Metals, Steel
Can Range: Typical Range Ø 202 – Ø 307 body diameters
Can Materials: Aluminum / Steel
Can Height Range: Typical Range 87 – 210 mm
Can Dome Depth Range: Typical Range 9 – 13 mm
Can Wall Thickness Range: 100-240 Volts/50-60 Hz
Compressed Air: 5 bar / 73 PSI
Weight: 620 kg Max.
Dimensions: (W) 1615 mm x (H) 1833 mm x (L) 3427 mm (with 4 lane conveyor)

Description
Brought to you by Torus, the Torus Automatic Total Quality (TQ) Lab is a fully configurable system capable of measuring thread, body, thickness, internal diameter, top load, volume, weight and burst pressures.
Plastic packaging requires precision measurement of many aspects, such as material thickness, outer body and neck physical dimensions, neck diameter and volume as well as load testing for crushing and pressure.
The Torus TQ-Lab is a unique, total quality testing station for plastic packaging such as plastic bottles and jars, typically used for soft drinks, health supplements, cosmetics, and domestic cleaning products.

Total Quality Testing
The TQ-Lab can undertake all the necessary tests on both empty and filled plastic containers or preforms in a single system. The multi-module concept improves accuracy and repeatability, reduces time and labor costs and saves on floor space in production environments. Once batches of plastic containers are placed onto the turnaround conveyor, the operator simply selects the relevant program and walks away.

Specifications
SKU: Torus_TQ_Lab
Applications: Burst Testing, Flexibility Testing, Optical Testing, Strength Testing
Component Materials: PET, PP, TRITAN, PEF, HDPE
Component Neck Finish: Thread, Continuous thread, split thread, PCO, SP, ROPP, Snap, Clinch
Component Shapes: Round, Round with petals, Oval, Square, Non-Symmetrical, Off-centre neck
Component Height Range: 80 – 400 mm
Component Gripper Pick Up Height: 75 – 395 mm
Component Outer Body Diameter Range: Ø 15 – Ø 160 mm
Component Internal Neck Diameter Range: Ø 15 – Ø 45 mm
Component Outer Neck Diameter Range: Ø 18 – Ø 54 mm
Component Weight Range: 5 – 3000 g
Power: 100-240 Volts / 50-60 Hz
Compressed Air: 6 bar / 87 PSI
Water: 1-2 BAR / 60-120ppm / 0.2mS-0.8mS
Dimensions: (W) 2930 mm x (H) 2280 mm x (D) 2020 mm

Description
Brought to you by Torus, our specialist testing brand, the Torus B305 Automatic Preform Inspection System offers a full range of modular inspection station options. It enables the customer to identify the inspection requirements and configure a system to suit the needs of the production facility.

Preform Inspection System
The Torus B305 Automatic Preform Inspection System is a modular system that can inspect and measure to find all of your preform defects. Each module can be selected by the customer allowing the configuration to suit your quality control needs. Dimensional measurements are calibrated automatically and can be traced to UKAS standards giving the user a full shot quality overview in approximately 15 minutes.

A full preform inspection system
Automatic thread start alignment provides unrivalled ‘absolute’ dimensional measurement system performance, for both Neck and Body features, traceable and certified to UKAS Standards.
Using state-of-the-art optical technology and illumination the system can provide a wide variety of defect analysis for features such as Gate and Seal, Body Defects and Plastic

Flow
The UV and Color Inspection quickly provides checks on UV transmission rates and Color data against customer preform specification.
The loading bowl feeder enables the operator to load full shots of preforms, with traceable measurement results provided by the Cavity Identification Module.
Customize your gauge!
Our modular gauge setups are unique and allow you to customize your gauge as and when you require, giving you the flexibility to ensure you have a total quality solution.
Add any of the below modules:

1. Cavity Identification Module
2. Weight Module
3. Dimensional Module
4. Body Inspection Module
5. Gate and Seal Module
6. UV and Color Module
7. Internal Diameter Module
8. Polarization Module

Specifications
SKU: Torus_B305
Applications: Deformation Testing, Optical Testing
Material Types: PET, PP, TRITAN, PEF
Component Colors: Opaque and Clear
Component Neck Finish: Thread, Continuous thread, Split thread, PCI, SP, ROPP, Snap, Clinch
Component Height Range: 60.00 – 200.00 mm
Component Outer Body Diameter Range: 40 mm
Component Internal Neck Diameter Range: Ø 16 – Ø 34 mm
Component Weight Range: 0-250 g
Component Neck Height: 35 mm
Electricity: 100-240 Volts / 50-60Hz
Compressed Air: 6 bar / 87 PSI
Dimensions: (W) 2930 mm x (H) 2280 mm x (D) 2020 mm

Description
Brought to you by Torus, our specialist testing brand, the Z401 Automatic Beverage Shell Inspection Gauge defines the standard for dimensional inspection of beverage / beer can shells.

Process
Each shell to be inspected is automatically collected from a ‘stack’ and loaded into the gauging module with an integrated pick and place system. The measurement cycle is then initiated via the PC running the TMS GaugeXplorer Measurement and Machine Control software.

Measurement Features of the Z401 Beverage Shell Inspection Gauge

• Unit Depth | Accuracy: +- 0.005 mm
• Countersink | Accuracy: +- 0.005 mm
• Panel Depth | Accuracy: +- 0.005 mm
• Curl Diameter | Accuracy: +- 0.005 mm
• Curl Height | Accuracy: +- 0.005 mm
• Curl Opening* | Accuracy: +/- 0.025 mm
• Inner Curl Diameter | Accuracy: +/- 0.025 mm
• Average Metal Thickness | Accuracy: +/- 0.005 mm

*Curl Opening feature not supported on CDL style shells

Additional Options
The Torus modular design construction gives complete flexibility when specifying your requirements.

Automatic Grain Alignment
The Automatic Grain Alignment option is available to add at any time.
The Grain Alignment option allows operators to gain information of where exact measurement points are taken, allowing for precise tooling adjustment to be made when required.

Description
Brought to you by Torus, our specialist testing brand, the Torus B303 Semi-Automatic Aerosol Burst Gauge monitors expansion volumes, and yield points to provide important information regarding the stability of the finished aerosol can.

Versatile aerosol burst gauge
With an expansion volume of up to 1800ml, the B303 Semi-Automatic Aerosol Burst Gauge covers the full range of industry aerosol containers.
Quick-change tooling provides the capability to cover a wide range of industry neck finishes, future production proofing the machine as customer requirements and portfolios develop. The system has the option of being mains water supplied or recirculating from a local water tank, reducing running costs and therefore cost of ownership.

Pressure and expansion options

• Mid-Range Pressure | 35 bar / 1.8 L

Measurement Features

• Burst Pressure | bar, PSI | Accuracy: +/- 0.2 bar
• Expansion Volume | ml | Accuracy: +/- 20.00 ml
• Expansion %
• Pressure Hold Out | Pass/Fail
• Yield Point Pressure | bar, PSI
• Yield Point Expansion Volume | %
• Test Time | Seconds

Description
Brought to you by Torus, our specialist testing brand, the Torus B309 Semi-Automatic Internal Diameter Gauge offers non-contact internal diameter measurements for plastic containers and preforms in a single operation with industry leading measurement range.
The proven contact measurement technology ensures accurate, reliable and traceable measurement 24/7.
Keep your B309 Semi-Automatic Internal Diameter Gauge with an enclosure. There is a floor standing industrial enclosure available for laboratory or shop floor environments.

Measurement Features

• Internal Diameter
• System Accuracy: Internal Diameter +/- 0.030 mm
• Ability to measure internal diameters at multiple heights (from TOF)
• Measures: Bottles, jars, containers and preforms

Specifications
SKU: Torus_B309
Applications: Beverage Testing, Optical Testing
Materials: Plastics and Polymers
Component Types: Bottles, jars, containers and preforms
Container Height Range: 30 mm – 460 mm
Neck ID Range: 8.5 mm – 145 mm
Max Body Diameter: 200 mm
Materials: PET, HDPE, TRITAN, PP (others)
Electricity: 100-240 Volts / 50-60 Hz
Dimensions: (W) 1450 mm x (H) 1850 mm x (D) 1100 mm
